High Voltage Switch

High Voltage Switch

Medical facility products require rugged solutions that withstand all disinfection processes and harsh chemicals.

Dangerous pathogens are omnipresent, particularly in medical facilities, posing a significant risk through contaminated surfaces. The battle against Hospital Acquired Infections (HAIs) demands rigorous and repeated cleaning protocols.
Medical environments require high-quality switches that meet stringent standards and can withstand frequent disinfection and exposure to harsh chemicals. To meet these critical needs, Barantech has developed an advanced high voltage switch. These switches are ultra-safe, aesthetically pleasing, and feature a solid-state design with no moving parts. Their robust and standardized design ensures seamless installation in any medical facility, providing a reliable solution to enhance safety and hygiene.

+ Electrical Connection

+ Mechanical Drawing

Electrical Data

    Switch Function
    ON/OFF
    Relay Voltage
    120VAC – 277VAC (RMS) max @ 16A
    Relay Switching Current
    16A max
    AC Input Voltage
    90-277 VAC (RMS)
    Actuation Force
    2-7 N
    Wires Function
    Black – Phase In
    Red – Phase Out (Output Relay)
    White – Neutral
    Green – Ground

Mechanical Data

    Housing Materials
    Black Volox 357U
    Front
    STS Plate
    Connection
    Load Wires 12 AWG, Ground wire 14 AWG, Length 7″ ±0.2″

Environmental Data

    Operating Temperature
    -15°C to +55°C
    Storage Temperature
    -20°C to +60°C
    IP Rating
    IP69

Key Characteristics

    Easy To Disinfect
    Barantech HVS switches, made of sealed aluminum, can be easily cleaned with copious amount of water or any detergent.

    Effortless
    As our HVS switch uses piezo touch technology – the switch can be operated with wet hands, gloves, or any other object.

    Built to Endure
    With no moving parts, it defies the harshest environments, ensuring  uninterrupted performance and longevity for your critical operation.

    The HV switch is flameproof
    Ensuring it can withstand extreme temperatures, ignition or fire hazards in high risk environments.
